Performance
Processor
Intel® Core 5 210H, 8C (4P + 4E) / 12T, P-core 2.2 / 4.8GHz, E-core 1.6 / 3.6GHz, 12MB Intel Smart Cache

AI PC Category
Non-AI PC

NPU
None

Graphics
Integrated Intel® Graphics

Chipset
Intel® SoC Platform

Memory
1x 16GB SODIMM DDR5-5600

Memory Slots
Two DDR5 SODIMM slots, dual-channel capable

Max Memory
Up to 64GB DDR5-5600

Storage
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®

Storage Slot
Two M.2 slots
• One M.2 2242 PCIe® 4.0 x4 slot
• One M.2 2280 PCIe 4.0 x4 slot

Max Storage Support
Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 2TB
• M.2 2280 SSD up to 2TB

Card Reader
SD Card Reader

Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec

Speakers
Stereo speakers, 2W x2, Dolby Audio™

Microphone
2x, Array

Camera
FHD 1080p + IR Hybrid with Privacy Shutter

Battery
48Wh

Power Adapter
65W USB-C® (3-pin)

Special Features
Modern Standby

Design
Display
16" WUXGA (1920x1200) IPS 400nits Anti-glare, 45% NTSC, 60Hz

Touchscreen
None

Screen-to-Body Ratio
90%

Pen
Pen Not Supported

Keyboard
Non-backlit, English (EU)

Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)

Dimensions (WxDxH)
356 x 253.5 x 17.5 mm (14.01 x 9.98 x 0.69 inches)

Weight
Starting at 1.7 kg (3.75 lbs)

Case Color
Arctic Grey

Case Material
Aluminium (Top), PC-ABS (Bottom)

Surface Treatment
Anodizing Sandblasting (Top), Texture (Bottom)

Software
Operating System
Windows® 11 Pro, English (US) / English (UK)

Bundled Software
Office Trial

Connectivity
WLAN + Bluetooth
Wi-Fi® 7, 802.11be 2x2 + BT5.4

WWAN
WWAN Not Supported

Ethernet
100/1000M (RJ-45)

Standard Ports
1x USB-A (USB 5Gbps), Always On
1x USB-A (USB 5Gbps)
1x USB-C® (USB 10Gbps), with USB Power Delivery 3.0 and DisplayPort™ 1.4
1x Thunderbolt™ 4, with USB PD 3.0 and DisplayPort™ 1.4
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x SD card reader

Docking
Various docking solutions supported via Thunderbolt™ or USB-C®.
For more compatible docking solutions, please visit Docking for ThinkBook 16 G9 IRL

Security & Privacy
Security Chip
Discrete TPM 2.0 Enabled

Physical Locks
Kensington® Nano Security Slot, 2.5 x 6 mm

Fingerprint Reader
Touch Style, Match-on-Chip, Integrated in Power Button

Other Security
Camera privacy shutter
IR camera for Windows® Hello (facial recognition)

Manageability
System Management
Non-vPro®

Service
Base Warranty
1-year, Courier or Carry-in

Included Upgrade
3Y Courier/Carry-in upgrade from 1Y Courier/Carry-in WHB (CPN)

Certifications
Green Certifications
ENERGY STAR® 9.0
EPEAT™ Gold Registered
ErP Lot 6/26
RoHS compliant
TCO Certified, generation 10

Mil-Spec Test
MIL-STD-810G military test passed

Other Certifications
TÜV Rheinland® Low Blue Light (Software Solutio
