Features
Finish:Brushed Stainless Steel
Net Capacity: 506l (353/153)
Ice & Water Dispenser
Non-Plumbed Water Tank
Large Capcity
PureFlat Door Design
Durable Inverter
Electronic Touch Control
Flat Duct
XXL Door Balcony
Big Box
Multi-use Beverage Tray
Supper cool function
Supper freeze Function
Multi Airflow
Total No frost
Digital Temperature Sensor
Soft LED Lights
Door Alarm
Product Dimensions (W*D*H) : 910*615*1786

Technical Specifications

Product identification
Description of appliance (Sigle Door,BM,TM,Triple Door,SBS, etc)
SBS
Type/appliance (Refrigerator, Larder, Freezer,Wine cooler,Beverage cooler)
R
FS (free standing) - BI (built-in) - BU (built-under)
FS

Aesthetics
Door profile                 ( F = flat  /  R = rounded  /  etc...)
F
Handle                           (External/Integrated)
Integrated
Colours    (White/Silver/SS/Glass/Inox looking/Sand color)
Inox looking

Basic features
Voltage / frequency
220~240 / 50Hz
Climate class     (SN=10~32°C, N=16~32°C, ST=16~38°C, T=16~43°C)
N/ST
Foaming components
C-P
Certifications  CB；
ERP
Energy
Capacity L
506
Net capacity fridge compartment L
353
Net capacity freezer compartment（4 star/2 star） L
153
Energy efficiency class
A+
Freezer compartment star rating/My Fresh Choice Room
4 star
Energy consumption  / year    kWh/year
395
Energy consumption (EN153) per 24 h  kWh/24 h
1,082
Rated Input power W
280
Defrost power W
206
Freezing capacity / 24 hours   kg/24 h
10
Max storage time by power failure  Freezer h
5
Max noise level dB(A)
40
Kind of coolant / Charge            (R134a/R600a) / grammes R / g
R600a/ 70g

Key features
Defrosting  Fridge / Freezer         (M=manual   A=automatic)
A/A
Control system                         (E = Electronic /  M = Mechanical)
E
Frost Free                             (Fridge/Freezer)
Yes/Yes
Multi airflow        (Fridge/Freezer)
Yes/Yes
Reversible door
No
Easy cleaning door seal
Yes
Crisper with humidity control function
No
Adjustable  shelves
Yes
Tempered glass
Yes
LED  Light        (Fridge/Freezer)
Yes/Yes

Control panel
Internal control display
Yes
Internal control display with LED/LCD
LED
Temperature range    (from>to)    °C
"Fridge:2℃≤tma≤8℃；
Freezer: -14℃≤tma≤-24℃；"
Super Cooling                             (Fridge)
Yes
Super Freezing                           (Freezer)
Yes
Child-Lock
No
Adjustable thermostat             (Y=Yes / N=No)
No

Fridge compartment
Shelves:
Number/type
3/glass
Colour    (w=white / lb=light blue / g=grey / t=transpar. / tk=teak)
t
Crisper(s)  :
Shelf (on  crisper)
1/glass
vegatable compartment：
number/color 2/crispers+1/water box（4.5L）
Door:
Storage rack(s)                                 (Total)
3/grey
Eggs tray(s) / Total number of eggs
2/12 holes eggs
Interior light W LED（2W）
top
Function parts
Wine rack nr. / type
1

Freezer compartment
Drawer(s)
2/drawer
Shelves:     Number/type
3/glass
Flap(s)
No
Storage rack(s) on the door                                   (Total)
1/grey
Colour of drawer  (w=white, t=transp.,  g=gray)
g
Ice cube tray(s)
1 movable ice cube tray
Interior light W  LED（2 W）
top

Others
Defrost water outlet
No
Adjustable feet                                        (front / rear)
2/0
Castors                                                    (front / rear)
2/2
Wall spacer grid or distance holder
No
Lenght of cable/incl. plug cm
200

Packing dimensions & loadability
Unit dimensions  with Integrated handle or  without handle     ( W / D / H ) mm
910*615*1786
Packing dimensions                       (W / D / H) mm
975*679*1910
Depth with open door mm
1096
Net weight  kg
87
Gross weight     kg
97
20GP/40GP/40HC Container load pcs
-/-/53
