Specifications



• Mini LED
• ULED Colour
• 144Hz Game mode Pro
• Hi View AI engine
• AI 4k Upscaler
• AI Smooth Motion
• AI Sports Mode
• Dolby vision Atmos
• Hands free voice control



Image display

Panel manufacturer

Hisense
Panel model

LCM:HD550J3U52-T0L3, Open Cell : T550QVN10.8
Active display area, horizontal dimension

1209,6
Active display area, vertical dimension

680,4
Screen size (rounded to nearest integer)

139
Screen size (rounded to nearest integer)

55
Display technology

LCD/ LED lit
Backlight source

Direct LED
Resolution (Horiz x Vert)

3840X2160
Screen curvature radius

-
Colour depth

8bit+FRC
Image refresh frequency

144
Smooth motion rate

240
3D image

-
Typical brightness of white

450nit（peaking 800nits）

Native contrast ratio

4000:1
Viewing Angle (Horiz / Vert)

178/  178
Quantum dot

Yes

KSF phosphor
No

UHD Premium

No
Response Time

6



Connectivity

RF- Radio frequency input

1
AV input

1
AV output

0
USB interface type 3.0 (Qty / List….)

1/ USB1
USB interface type 2.0 (Qty / List ….)

1/ USB2
Optical digital audio output (SPDIF)

1
Earphone jack

1



HDMI ports

HDMI inputs

4
HDMI type 8K@60Hz

No
HDMI type 4K@60Hz with HDCP version 2.2

Yes
HDMI 2.1  compliant input

Yes / HDMI 3 & 4
Enhanced Audio Return Channel ( eARC)

Yes / HDMI 3
CEC- Consumer Electronics Control via HDMI

Yes



Smart TV

Ethernet port (RJ45 connector)

1
Wi-Fi  protocols IEEE 802.11 {b, g, n, ac, ad, ..}

a, b, g, n, ac
Wi-Fi bands

2.4/5.0
DLNA compliance

Yes
Bluetooth / BT version

Yes / 5.0
Anyview (Screen mirroring)

Yes
BVOD services (Iview,  SBS on Demand, 9Now, 7Plus, Tenplay)

Iview,  SBS on Demand, 9Now，tenplay

Installed Applications {List ……}

Netflix/Youtube/Prime Video……
Freeview Plus - HbbTV 2.0

Yes
Web browser [Chrome | Opera | Other]

Odin



Digital TV reception

Digital broadcating (DVB-T / DVB-T2)

Yes / Yes
Video decoder (MPEG2 / MPEG 4)

Yes / Yes
LCN- Logical channel number and DTV Service name support

Yes
Teletext  / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX

Yes / Yes / 4:3
Subtitles

Yes
EPG- Electronic programming guide, 7 days for all services

Yes
Audio description (vision impairment aid)

Yes
Parental rating lock

Yes
Analog Tuner

Yes



Image processing

Backlight control

Yes
Light sensing

Yes
Dynamic backlight control

Yes
Frame rate control

No
Variable Refresh Rate (VRR)

Yes
Freesync Premium

Yes
Auto Low Latency Mode for VRR

Yes
Local dimming/ controllable zones

Yes/ 100+
Zoom function settings

Auto/ 16:9/ 4:3/21:9/Movie Zoom/ Dot to Dot
HDR - High Dynamic Range for luminance (DMP / Netflix / HDMI)

Yes / Yes/ Yes
HDR system (HDR10 / HDR10+ / Dolby Vision)

Yes /Yes/Yes
HLG (Hybrid Log-Gamma) for HDR

YES
HEVC (H.265) decoder

YES
Motion enhancement and compensation (MEMC)

YES
Picture mode

Standard,Enhanced（ACR),FILMAKER,Cinema,Engergy Saving,Dynamic,Sports



Sound

Audio power output per channel

2*10W+20W
Number of speakers (Tweeter / Midrange / Woofer)

0 /2 /1
Automatic volume level (AVL)

Yes
Audio equalizer

Yes
Dolby Digital

Yes
Audio enhancement -Type {SRS, BBE, SAP, DBX-TV….}

Dolby ATMOS

Lip-sync  adjustment

Yes
Sound mode

Standard,Enhanced(ACR),Theatre,Music,Speech,Late Night,Sports.



Features

On/off timer

Yes
Power off if no signal

Yes
Sleep timer

Yes
Program lock

Yes
OSD transparency control

Yes
User interface

VIDAA U8.5
Software version OSD indication

Yes
Legal requirements: Disclaimer / Acceptance of Terms

Yes / Yes
Favourite channels list

Yes
Electronic point of sales (E-POS)

Yes
OTA- Over the air software updates

Yes
Voice command

Yes
Screen mirroring {Miracast, Anyview Cast, ...}

Anyview Cast
Smartphone remote control application {Rremote Now, ...}

vidaa app
Replaceable demo video for Store mode

Yes
Remote control via serial port

No



USB media player

Personal Video Recorder

Yes
Time Shift

Yes
DTV Recording (EPG scheduling / start from Standby )

Yes / Yes
DivX decoder

No
MPEG4 (H.264) / H.265 decoder

Yes / Yes
DMP- Digital media player content (Music / Video / Photos / Text)

Yes / Yes / Yes / No
DMP Auto-play

No
DMP for UHD content via USB

Yes
DMP File allocation table (FAT / FAT32 / exFAT / NTFS)

Yes / Yes  / No / Yes
PVR  File allocation table (FAT / FAT32 / exFAT / NTFS)

Yes / Yes  / No / Yes



Hotel lock

Protected Hotel lock submenu (Password / fixed code)

No / Yes
Clone function for programs, sound and image settings.

Yes
Sub-menu lock, including tuning lock

Yes
Keyboard lock

Yes
Maximum volume lock

Yes
Power on volume

Yes
Power on, apply default sound/image settings

No
Power on source selection

Yes
Power on RF channel selection

Yes
Power on mode (On / Standby / Last)

Yes / Yes / Yes
Inputs access (Enable / Disable)

Yes



Hardware

Processor / Cores

MT9618GADTAB
Dual Tuner

No
Colour (Front bezel, rear, stand)

Tarnish / Black /  Tarnish
Speakers mounted in enclosure

Yes
Mains  power switch

No
Swivel base

No
Compact packaging

Yes
Supply  range [Voltage / Frequency ]

AC100~240V,50Hz/60Hz
Standby consumption

< 0.5W
Maximum time delay Power On to sound an image

30



Installation

Stand area (Width / Depth)

1004×313
Wall mount dimensions (Horiz x  Vert)

400*200
Wall mount, screw thread

M6*15
VESA compliance

Yes
Detachable power cord

Yes
Power cord length

155



Accessories

Remote controller (Technology / Part number )

IR /ERF2R38H
Battery (size / quantity)

AAA / 2
User manual (Available online) / Quick setup guide (Print)

1 / 1
Warranty [In User manual | In separate sheet]

In separate sheet
Skype camera (Qty / Part number)

-
3D glasses type  [Passive | Shutter] / Link [RF | IR | BT]

-
3D glasses (Qty / Part number)

-



Dimensions

Dimensions with stand (W x H x D)

1226×784×313
Dimensions without stand (W x H x D)

1226×713×78
Carton box dimensions (W x H x D)

1387×874×142
Net weight (with stand / without stand)

14.0/13.5
Gross weight

18,5
Container load (20ft / 40ft / 40ft HC)

132/268/402



Licensing and certification

EMC- Electromagnetic Compatibility

Yes
CB- Electrical safety

Yes
HDMI

Yes (Hisense internal test)
Dolby Digital

Yes
MEPS- Test report

Yes
ROHS

No
Electrical safety  conformity for Australia

Yes
