SPECIFICATIONS

Weight  7.5kg(16.5 lbs)
Dimension (H X W X D)  180 x 525 x 214 mm.  184 x 525 x 214 mm (with Rubber Feet)
Design  2-way bass reflex
Unit Measurement  1 Piece
Sensitivity  87dB (2.83V/1m)
Frequency Range Free Field  57Hz-50kHz (-6dB)
Frequency Response  68Hz-28kHz (±3dB)
Maximum Output  108dB
Amplifier Requirements  10-100W
Nominal Impedance  8 Ohms (min. 3.4 Ohms)
Drive Units
130mm (5.25in.) aluminium Uni-Q
25mm (1in.) vented aluminium dome HF
2 x 130mm (5.25in.) aluminium ABR
Crossover Frequencies  2.5kHz
