Specifications

 Capacity
 Capacity (Cooling, Btu/hr): 10697 Btu/hr
 Capacity (Heating, Btu/hr): 11004 Btu/hr
 Capacity (Cooling, kW): 3.14 kW
 Capacity (Heating, kW): 3.23 kW

 Energy Efficiency
 EER (Cooling, W/W): 3.10 W/W
 COP (Heating, W/W): 3.72 W/W
 EER (Cooling, Btu/hW): 10.58 Btu/hW
 COP (Heating, Btu/hW): 12.69 Btu/hW

 Noise Level
 Noise Level (Indoor, High/Low, dBA): 39/29 dBA
 Noise Level (Outdoor, High/Low, dBA): 50 dBA

 Electrical Data
 Power Source(Φ/V/Hz): 1 / 220~240 / 50
 Power Consumption(Cooling, W): 1011 W
 Power Consumption(Heating, W): 867 W
 Operating Current(Cooling, A): 4.60 A
 Operating Current(Heating, A): 3.80 A

 Physical specification
 Gross Dimension (Indoor, WxHxD, mm): 921×281×379 mm
 Gross Dimension (Outdoor, WxHxD, mm): 823×595×358 mm
 Net Dimension (Indoor, WxHxD, mm): 845×289×209 mm
 Net Dimension (Outdoor, WxHxD, mm): 782×540×320 mm
 Gross Weight (Indoor, kg): 12.5 kg
 Gross Weight (Outdoor, kg): 31.5 kg
 Net Weight (Indoor, kg): 10.5 kg
 Net Weight (Outdoor, kg): 29.0 kg
 Loading Quantity (20/40/40Hft without Pipe): 105/212/245

 Technical Information
 Piping Length (Max, m): 20 m
 Piping Height (Max, m): 10 m
 SVC Valve (Liquid (ODxL)): 6
 SVC Valve (Gas (ODxL)): 12
 Moisture Removal (l/hr): 1.20 l/hr
 Air Circulation (Cooling, ㎥/min): 650 ㎥/min
 Refrigerant (Type): R410A
 Low Ambient (Cooling, ℃): 18~43 ℃
 Low Ambient (Heating, ℃): -7~24 ℃

 Air Flow
 Air Direction Control (Up/Down): Auto
 Air Direction Control (Left/Right): Manual
 Air Flow Control Step (Cool/Fan): 3 Step

 Convenience
 Indoor Temp. Display: Yes
 Display On/Off: Yes
 24-Hour Timer: Yes
 Auto Restart: Yes

 Operating Mode
 Auto Mode: Yes
 Fast Cool: Yes
 Good Sleep: Yes
 Dehumidification: Yes
 Fan Mode: Yes

 Smart
 WiFi Embedded: No

 App Connectivity
 SmartThings App Support: No
