Wharfedale Elysian 3 – Floorstanding Speakers Pair
he Wharfedale Elysian 3 has led the Wharfedale engineers to create a benchmark in affordable, audiophile-grade luxury loudspeakers. A genuine example of luxury audio, ELYSIAN offers indulgence in design, materials, aesthetics and performance. Cutting edge design and class-leading technology are combined to deliver musical reproduction that will proudly challenge the world’s finest loudspeakers.
From the genuine Piano-Lacquer finished cabinet, created with details of true craftsmanship, through to the AMT (Air Motion Transformer) high frequency transducers and European manufactured bass drivers, ELYSIAN represents a new standard in the world of home audio experiences. The resultant sound, from the finely balanced driver selection and expert crossover design, matches the pristine design with a degree of natural transparency that will leave you breathless.
ELYSIAN Bass
The bass units are loaded by the most advanced version of the unique Wharfedale Slot Port yet. Christened SLPP (Slot Loaded Profiled Port) the rear output of the bass units is not wasted. Instead the lowest frequency energy is vented to a slot at the base of the speaker, specially profiled to equalize the high internal pressure to the low pressure in the room. Overall system sensitivity is incredibly high, typically more than 92dB output for just 1 watt of input, allowing any amplifier to reveal the full dynamic range of the music fed to it without any strain or limitation.
ELYSIAN Crossover
Combining the outputs of the drivers is an advanced computer modeled crossover that has been developed over hundreds of hours of listening tests, fine tuned to make sure that the blend between the drive units is seamless. Of particular note is the phase consistency across the drive unit output, allowing a wide range of seating position and encouraging the power response to be highly linear throughout your listening room. And, of course, we have only used the highest grade, acoustically transparent components throughout the crossover construction, ensuring that you hear all the musical detail with nothing held back.
Please view our full catalogue of products
Please view our online shop of products
General Description: 3-way floorstanding speaker
Enclosure: Type Bass reflex
Transducer Complement: 3-way
Bass Driver: 7″ (180mm) coated fibre glass
matrix cone x 2
Midrange Driver: 6″ (150mm) coated fibre glass
matrix cone
Treble Driver: 27 x 90mm AMT
AV Shield :No
Sensitivity (2.83V @ 1m) :89dB
Recommended Amplifier Power: 30-200W
Peak SPL: 108dB
Nominal Impedance: 4Ω (compatible 8Ω)
Minimum Impedance: 2.3Ω
Frequency Response (+/-3dB): 44Hz ~ 22kHz
Bass Extension (-6dB): 35Hz
Crossover Frequency: 375Hz, 2.9kHz
Cabinet Volume (in litres): 9.4L, 35L
Dimensions (mm)
Height (on plinth): 1050mm
Width (on plinth): 263mm
Depth (with terminals): (285+30)mm
Carton Size: 425 x 415 x 1155
Net Weight: 28.45kg/pcs
Gross Weight: 35.37kg/ctn
